ecoDrives EL2 90-S2 - AC motors with running and starting capacitor ++ EMM

Name: Single-phase motor with operating and starting capacitor
Brand: ecoDrives
SKU: 36276
Price: 274.89 EUR
Availability: InStock

Single-phase motor with operating and starting capacitor

Manufacturer/Type: ecoDrives EL2 90-S2

Item no: 36276

Selected configuration

Reconfigure

231,00 EUR

274,89 EUR incl. VAT plus Shipping costs

Quantity

Technical data

Voltage	230V/50Hz/1ph
Rated current	8,19 A
Power	1,5 kW
Rated speed	2860 rpm
Efficiency class	IE2 (High Efficiency)
Efficiency at 100% nominal load	81,3 %
Protection class	IP55
Insulation class	F
Operating mode	S1 (continuous operation)
IEC size	90S
Design	B34K
Flange size	C140
Shaft end (dxL)	24x50 mm
Bearing d side	Non-locating bearing/6205-2RZ-C3/lubricated for life
Bearing n-side	Non-locating bearing/6205-2RZ-C3/lubricated for life
Color	RAL7024
housing	Aluminium
Weight	14,40 Kg

Description

Product description
Single-phase asynchronous motor with operating and starting capacitor in accordance with IEC standard (EN 60034/IEC 60072). Suitable for a wide range of drive tasks in private and commercial environments. The starting capacitor provides a higher starting torque. An integrated electronic starting relay switches off the starting capacitor once the rated speed has been reached.

Features

Quality product with excellent price-performance ratio
Low weight due to aluminium housing
Enclosure powder-coated in C2 (for outdoor installation, roofed)
Variable terminal box position (top/left/right - by screwing the feet over)
Motor protection (PTC thermistor) as standard

Scope of delivery

Motor with ready-to-connect terminal box (with terminal diagram) incl. 2 cable glands
Shaft with feather key
Radial shaft seal d-side
Operating and maintenance instructions online under "Documentation"

Instructions

The motor is delivered with the direction of rotation to the right. By changing the terminal assignment
direction of rotation to the left is also possible
Circuit diagram for changing the direction of rotation with pole changeover switch under "Documentation"

Data blisters and drawings (German only)

Data and dimension sheet

Download

CAD-DATEI_STEP_36276.zip

Download

Dokumentation

Circuit diagram change of direction of rotation with pole changeover switch for single-phase motor
(ca. 0,3 MB)

Download

Radial and axial forces
(ca. 0,2 MB)

Download

Operating and maintenance instructions (DE/EN)
(ca. 1,5 MB)

Download

Product configurator

This product can be configured. The selected options are displayed in the order information and the product price and delivery time are updated automatically.

Notes on option selection (German only) (other options available on request)

IP55 (Standard - 0,00 EUR)

Top/right/left (Standard - 0,00 EUR)

1 set (3 pcs.) PTC thermistors (Standard - 0,00 EUR)
